The Rainger Revo-X 1.3 is a premium hard shell roof top tent designed to do more than just look good on a parked vehicle. It was built to set up fast, sleep properly, ventilate intelligently, carry its own integrated solar system, and hold up to real Australian touring — with the kind of detail, comfort and serviceability that cheaper tents only pretend to offer.
Just as important, when you buy a Revo-X, you know who is behind it. In an industry full of importers, rebadged products and weak after-sales support, Rainger backs its gear with direct advice, fitment help, spare parts and real product knowledge before and after the sale.
Rainger is known for genuine innovation across multiple product lines. From swags and rooftop tents to awnings, brackets and touring accessories, our focus has always been the same: build smarter products, solve real-world problems, and keep improving the details that matter once you are actually out there using them.
In stock. Ready to ship Australia-wide or collect from Baringa, QLD.
Available in Desert Tan (two-tone with black) and Midnight Black.
At a glance:
- X-Frame elevation + Rear Fold design for more usable internal space
- 100mm dual-density mattress + 15mm anti-condensation mat
- 5-opening ventilation system with included magnetic USB fans
- 295W integrated solar with internal wiring and 12V hub
- 320GSM ripstop blackout canvas with hard shell weather protection
X-Frame & Rear Fold — Compact Footprint, Bigger Usable Space
The Revo-X 1.3 uses the same X-Frame and Rear Fold architecture that makes the wider Revo-X feel so different to a conventional hardshell.
-
30% more usable internal room from the X-Frame elevation design
-
20% more space again from the Rear Fold layout
- Better headroom and foot-end room than a conventional hardshell of similar footprint
- Compact outer dimensions without the usual cramped feel inside
Most hardshell roof top tents open on a single hinge. The X-Frame uses a crossed-strut elevation system that lifts the shell higher at both the head and foot ends, creating real internal volume where campers actually feel it — sitting up, turning over, getting changed, or spending more than one night in the tent.
The Rear Fold adds more than just extra room. On many hardshells, the head-end canvas folds inward and rain naturally runs down toward the sleeping end of the tent. The Revo-X changes that path. The rearward extension helps stop that panel acting like a moisture channel above your pillows.
Because the Rear Fold extends under the integrated awning fly, it also allows a protected top roof vent that stays covered from rain. More space, better ventilation, and retained weather protection do not usually come together in a compact hard shell.
100mm Mattress — Compact Tent, No Compromise on Sleep
The mattress is one of the easiest places for a compact roof top tent to fall short. We did not let that happen here.
- 100mm dual-density foam
- Eggshell-profile comfort layer
-
1130 x 1970mm sleeping surface
- 15mm anti-condensation mat underneath
- Bedding stores inside when closed
The Revo-X 1.3 uses the same mattress philosophy developed over seven years and thousands of swags. The eggshell top profile helps distribute body pressure, improve airflow across the sleeping surface, and reduce the harsh feel of sleeping above an aluminium shell floor.
That matters because a roof top tent mattress has a different job to do than a swag mattress. In a hardshell, it sits over a solid aluminium shell that can hold cold or radiate heat. The foam has to support comfort and act as an insulation layer between your body and the shell underneath.
The tent stores your bedding inside when closed. Sheets, doona and light pillows stay packed in. One strap pulls it down. Four laser-cut latches lock it shut.
320GSM Canvas — SGS Tested, Waterproof, UV Rated, Built to Last
320GSM ripstop canvas with a PU coating rated to 10,000mm hydrostatic head and UV+50 protection. Rear awning fly is 300GSM synthetic at PU 5,000mm UV+50. Every seam sealed. Every opening finished with upgraded heavy-duty nylon edging.
-
SGS tested canvas performance
-
95/100 water repellency result
-
UV Grade 4.5/5 under accelerated testing
- Ripstop grid helps stop tears propagating across a panel
- PU-backed internal walls stay more manageable when moisture forms
We publish these numbers because most competitors do not. Water repellency scored 95 out of 100. UV resistance rated Grade 4.5 out of 5. The fabric is also certified free of harmful phthalates.
The ripstop grid stops tear propagation. If a thread is damaged by a branch, abrasion, or repeated use, the failure is more likely to stop at the next grid point instead of running across the entire panel.
Internal walls are PU-backed and vacuum heat-sealed — not just coated on the outside face. That means any condensation that forms stays on the surface where it can be wiped away, rather than soaking in and sitting damp between trips. Read more on mould prevention, canvas construction, and waterproofing and seal integrity.
Every window and door uses superfine anti-cut nylon insect mesh designed to handle repeated zipping and use better than standard RTT mesh.
5 Ventilation Openings — True Crossflow in a Compact Hardshell
Ventilation is the single biggest difference between a roof top tent that feels easy to live in and one that becomes damp, stuffy and frustrating after a few nights.
- Left full door
- Right full door
- Rear full door
- Front foot-end panel
- Protected top roof vent
- 2 included magnetic USB-rechargeable fans
Most hardshell, clamshell, and wedge-style tents have three openings. The Revo-X has five. Each opens independently, letting you create real crossflow at different wind angles, campsite orientations, and weather conditions.
The rear canvas door zips from the bottom up, which is effectively unique in this class. Opened with the foot-end panel, it helps create low-level crossflow at mattress height — exactly where cool air pools and the condensation cycle starts.
Two included USB-rechargeable fans mount magnetically near the roof vent. They run from their own internal lithium batteries, so they do not rely on the vehicle power system just to move air overnight.
Under the mattress, a 15mm anti-condensation mat creates an air gap above the aluminium shell floor. The 100mm mattress provides insulation from the shell surface. PU-backed internal walls help keep any surface moisture manageable. This is a layered system, not one gimmick fix.
We do not claim the Revo-X eliminates condensation. No tent can. Condensation is physics. What the Revo-X does is reduce it substantially compared to conventional hard shells and make any moisture that does form easier to control, dry and clean. Read our condensation guide and storage guide.
295W Integrated Solar — Properly Mounted, Properly Wired, Standard
The Revo-X 1.3 includes a 295W full-black monocrystalline PERC half-cell solar panel, slimline rack, and internal wiring as standard. No loose external cables. No guessing what fits. No needing to bolt on an awkward third-party panel later.
- 295W full-black monocrystalline solar panel
- Internal wiring included as standard
- Dedicated slimline rack with natural air gap beneath panel
- Dual Anderson plugs ready to integrate into your setup
- 12V hub with cig sockets, USB-A, USB-C QC and voltage display
The panel uses a 72-cell 6x12 half-cell configuration with 22.23% module efficiency. Half-cell design helps reduce hot spotting and improves output under partial shading.
Why a Glass-Framed Panel Instead of Stick-On Solar
Semi-flexible stick-on panels bond directly to a lid with no air gap, holding more heat and making replacement messy. Integrated lid solar ties the panel directly to the tent structure, limiting future upgrade and service options.
The Revo-X uses a conventional glass-framed module on a dedicated rack with airflow underneath. Cooler cells mean more stable real-world output. If the panel ever needs to be serviced or replaced, it unbolts cleanly without turning the tent lid itself into the problem.
Important — the solar output is unregulated. Vmp 19.31V, Voc 24.30V, Imp 15.28A. You'll need a compatible MPPT/PWM regulator or DCDC/BCDC charger with solar input. We stock the Victron 100/20 Smart Solar Regulator as a purpose-matched option. Check with us before you order.
Download full NES72/295W Solar Spec Sheet (PDF)
12V Power Hub & Connections
The tent includes an internal 12V hub with 2 x cigarette sockets, USB-A, USB-C QC and a voltage display. Dual Anderson plugs sit plug-and-play ready — grey for 12V in, red for solar out — plus a rear AUX port. A dedicated heat-proof diesel heater port is also built into the system for compatible setups.
Weight Transparency — Compact Size, Honest Numbers
Tent: 92kg. Solar panel + rack: 20.7kg. Total installed weight: approximately 112.7kg.
That is the real installed figure — not just the shell weight by itself. We include the tent, solar panel, rack and wiring because that is how the tent is actually going to be used.
Most competitors quote the shell only, then leave the rest to be added later. Once you add solar, rack and wiring to many competing setups, their final installed weight is often much closer than the advertised headline number suggests.
Unsure whether your rack, canopy or trailer setup is suitable? Contact us before you order and we will confirm compatibility before anything ships.
Why We Built the Revo-X Differently
Seven years manufacturing thousands of swags taught us what actually goes wrong when Australians sleep outdoors. Thin mattresses. Weak airflow. Undersized power options. Materials that look fine on a showroom floor but show their shortfalls after real use.
The Revo-X project started with a simple goal: build a hard shell roof top tent that felt better resolved from the start. Not a generic import with a few features bolted on, but a system where the mattress, ventilation, solar integration, weather sealing and serviceability all worked together.
That same approach runs across the wider Rainger range. We are not interested in chasing the lowest common denominator. We would rather innovate properly, refine the details, and back the product long after the first sale.
Technical Specifications
| Closed dimensions |
1300 x 2150 x 175mm |
| Colours |
Desert Tan (two-tone with black) | Midnight Black |
| Height with rack & solar |
215mm total |
| Mattress |
1130 x 1970mm | 100mm dual-density eggshell foam |
| Tent weight |
92kg |
| Solar + rack weight |
20.7kg |
| Total installed weight |
~112.7kg (all-in: tent + solar + rack + wiring) |
| Solar panel |
295W full-black monocrystalline PERC | 72 half-cells | Glass-framed slimline module |
| Solar output |
Unregulated | Vmp 19.31V | Imp 15.28A | Voc 24.30V | Regulator or DCDC with solar input required |
| Tent canvas |
320GSM ripstop | PU 10,000mm | UV+50 | Seam-sealed | PU-backed internal walls |
| Awning canvas |
300GSM synthetic | PU 5,000mm | UV+50 |
| Mesh |
Superfine anti-cut nylon — all windows and doors |
| Ventilation |
5 independent openings | True crossflow | Rain-protected top vent |
| Fans |
2x USB rechargeable | Internal lithium | Magnetic mount | Removable |
| Anti-condensation mat |
15mm black mesh |
| Ladder |
2.3m telescopic | Hook & pin lock | Angled wide steps |
| Closure |
4x laser-cut latches | 1-strap pull-down |
| 12V power hub |
2x cig sockets | USB-A | USB-C QC | Voltage display |
| Anderson plugs |
Grey 12V in | Red solar out | Rear AUX port |
| Lighting |
3x dimmable LED strips |
| Storage |
Overhead tablet pocket + 4 side gear pockets |
| Heater port |
Heat-proof diesel heater port | Zipper | AC hose compatible |
| Warranty |
2 years — manufacturing defects |
Vehicle Compatibility
The Revo-X 1.3 mounts to touring vehicles, alloy ute canopies, load bar setups, camper trailers, and jet ski or motorbike trailers.
Rhino Rack, ARB, and Front Runner systems may need additional hardware — contact us before you order and we will confirm compatibility before anything ships.
Serviceability & Accessories — A Tent You Can Keep Running
Every component that wears should be replaceable. That is how we think about the Revo-X platform.
The canvas body unzips from the top and rotates out via a bottom sail track system. If your canvas is ever damaged or reaches end of life after years of use, it can be replaced without buying a whole new tent.
Accessories (sold separately): Quick Release Shower Tent Mounts | Recovery Board Mount Kits (Maxtrax, TRED) | Redarc BCDC Alpha 50A | Victron 100/20 Smart Solar Regulator | 8 Pack Tent Track Accessory Mounting Hardware Kit | 3rd Roof Load Bar | Rainger 270° Awning Brackets for Revo-X RTT | Narva Ultima 48” Light Bar Kits | Narva Ultima 8” Quad Lighting
View One in Person
The Revo-X is available to view open and set up at:
-
Rainger HQ — Baringa, Sunshine Coast QLD. By appointment. Book here.
-
Roam Offroad — Gawler, Adelaide SA
We attend camping and 4WD shows throughout the year — get in touch to find out where we'll be next.
Shipping & Pickup
Pickup: Baringa, QLD (Sunshine Coast) — by appointment only. No onsite installs.
$350 flat rate shipping to Mainfreight depots in QLD, NSW, VIC and ACT:
QLD: Larapinta, Narangba, Townsville, Mackay.
NSW + ACT: Sydney, Newcastle, Albury, Kembla, Canberra, Dubbo.
VIC: Epping, Ballarat, Dandenong, Geelong, Bendigo.
Depot pickup within 14 days — storage charges may apply after this period. No residential delivery.
WA, NT, TAS, SA: Email for a shipping quote.
Prefer a local install? Ask your local 4WD store — we support wholesale distribution and installs Australia-wide. Contact us and we'll make it happen.
Full details: RTT FAQ | Shipping & Delivery Policy
Speak to the People Who Built It
When you call Rainger, you get us. Not a call centre. Not a bot. The people answering your questions are the same people who worked through the mattress, canvas, solar rack layout, and fitment logic behind the Revo-X platform. A serious purchase deserves a direct conversation with the people behind the product.
(07) 5211 0841 | Mon–Fri 8:30am–4:30pm | Sat by appointment
Contact us online | RTT FAQ | RTT FAQ Blog
Frequently Asked Questions
Does the Revo-X 1.3 get condensation?
Yes — every roof top tent does. Condensation is physics, not a design flaw. What the Revo-X 1.3 does differently is significantly reduce it through five independent ventilation openings for true crossflow, two magnetic USB fans for active airflow, a 15mm anti-condensation mat creating an air gap above the shell floor, and PU-backed wipeable internal walls that do not absorb moisture. Any condensation that forms is easier to wipe away and manage.
How much does the Revo-X 1.3 weigh fully installed?
Approximately 112.7kg all-in — that includes the tent (92kg), the 295W solar panel, slimline rack, and internal wiring (20.7kg). We publish the total installed weight because many competitors only quote the shell weight without the components buyers usually end up adding later.
Do I need a solar regulator with the Revo-X 1.3?
Yes — the 295W panel output is unregulated. You will need either a standalone MPPT/PWM solar regulator or a DCDC/BCDC charger with solar input. Many popular units from Redarc, Projecta, Enerdrive, Victron and Renogy will suit. Contact us before ordering and we will help confirm compatibility with your setup.
What vehicles does the Revo-X 1.3 fit?
The Revo-X 1.3 mounts to touring vehicles, alloy ute canopies and load bar setups, camper trailers, and jet ski or motorbike trailers. Rhino Rack, ARB, and Front Runner systems may require additional mounting hardware. Contact us before you order and we will confirm compatibility with your specific setup before anything ships.
Can I store bedding inside the tent when it is closed?
Yes. The Revo-X 1.3 stores your doona, light pillows, and sheets inside the shell between trips. One strap pulls the tent down and four laser-cut latches lock it shut, so pack-up stays quick and simple.
What is the difference between the Revo-X 1.3 and 1.45?
The 1.3 is 150mm narrower across every external dimension. The core Revo-X design philosophy remains the same: X-Frame elevation, Rear Fold, integrated solar, ventilation system, mattress spec, and practical touring features. The 1.45 suits buyers wanting more width and room. The 1.3 suits buyers wanting a tighter footprint without giving away the core spec.
Can I replace the canvas if it gets damaged?
Yes. The canvas body unzips from the top and rotates out via a bottom sail track system. If the canvas is ever damaged or reaches end of life after years of use, it can be replaced without buying a whole new tent.
Where can I see the Revo-X 1.3 in person before buying?
The Revo-X is available to view open and set up at Rainger HQ in Baringa on the Sunshine Coast by appointment, and at Roam Offroad in Gawler, Adelaide SA. We also attend camping and 4WD shows throughout the year — contact us to find out where we will be next.
